3m Width Welded Wire Mesh Panel Fence Machine for Uzbekistan Customer+Wire Mesh Bending Machine
1. All the components used are with world famous brand. For oversea customers, it is very easy to get the parts locally.
2. PLC controlled. Easy to set and control. It makes this machine more intelligent and reasonable.
3. The greatest advantage is possible to adjust the distance of line wires at random on the same mesh panel.
4. The welding wire diameter is able to be made to orders. The range of our mesh welding machine is from 3mm to 12mm. Material can be stainless steel wire, galvanized wire, plain steel bar, cold rolled rebar, hot rolled rebar.
5. The machine line automatic degree can be according to request. For the economical type, line wire and cross wire are pre strengthened and cut to length. We capable to produce fully automatic machine.
wire diameter | 2.5-6.0mm |
width | 3000mm |
mesh size | 50x50-300x300mm |
length | 6m |
speed | 40-60 times/min |
Voltage | 380v 415v 50hz |
Line wire feeding | Pre-straitening&Pre-cut |
cross wire feeding | Pre-straitening&Pre-cut |
Exterior size | 3500X2100X1500mm |
Weight | 3600kg |
